TS-SP

  • 7200 mcd highly efficient rear light
  • 240-degree wide visibility
  • 6V(5V ~ 16V) with a power consumption of 0.6 Watt
  • For ø27.2mm, 30.9mm, and 31.6mm seat post
  • IP56- Protects against high pressure water or dust ingress
  • For 25km e-bike / EPAC
  • K-Mark & ISO-6742  compliance
Product Description
RoHS
圣维兹
中央电气
ISC6742
抵达

Compliant with StVZO and ISO 6742; meets CE, RoHS, and REACH—road-legal beam that rides courteously in Europe.

Specification
Model Name TS-SP
Model No. TKSESP1-316
TKSESP1-272
S/N B03
Light Output 7200mcd/ 20 lumens
Optical Technology LTi
Light Source LED *4
Input Voltage (DC) 6V(5V ~ 16V)
Power Consumption 0.6W
Cable Diameter ø3mm
Cable Length 1400mm
IP Rating IP56
Operating Temperature (°C) -25 ~ +70
Material Plastic
Weight (et. cable) 18g (without adapter)
Dimension (WxHxL) 38 x 18 x24mm (without bracket)
Mounting Option TKSESP1-316: ø31.6 & 30.9mm seat post
TKSESP1-272: ø27.2mm seat post
Reflector (Optional) N/A
Compliance CE/RoHS/ REACH/ Prop 65
Type of Approval StVZO-K & ISO-6742
Approval Number ~ K1693
Video Demo

×

System Compatibility

System Compatibility- Download

Illuminate your path

Available for Ø 27.2 / 30.9 / 31.6mm seat posts

Rear Bright 1

Rear Bright

Outputs 20 lm with LTi lenticular optics creating a 3D-like pattern seen from more angles; an auxiliary retro-reflector adds visibility to traffic.

240° View

Wrap-around visibility up to 240° helps you get seen from more angles—confidence at junctions, in traffic, and on shared paths.

TS 240° View
TS Seat Post Fit

Seat Post Fit

Mounts cleanly on seat post with plug-in cabling—quick install, tidy routing, and easy swaps; fits ø27.2 mm, 30.9 mm, and 31.6 mm seat posts.

Weather Ready

IP56 sealing resists spray and dust to keep visibility steady on commutes and gravel detours—durable performance through the seasons.

TL Weather Ready2 1
TS Low Power Consumption

Low Power Consumption

Efficient draw on 6 V e-bike systems minimizes load and heat while maintaining signaling; tuned for EPAC 25 km/h integration with 5–16 V input.

Additional information

Mounting Position

Seat Post

Power Cable

1400mm Open + Self-sealing connector

Mount / Bracket

Seatpost Bracket / Mount (for Ø31.6 & 30.9mm), Seatpost Bracket / Mount (for Ø27.2mm)

Compliance

CE, ISO-6742, RoHS/ REACH, StVZO-K

Light Type

Tail Lights

Max. Light output

< 50 Lumens (Be Seen)

Power source

E-Bike

Mounting

Seatpost

Riding scenario

City/ Urban Area, Rural Area
